OPERATION DETAILED CONTROLS AND GAUGES
3-141
TOOL, CAN STORAGE PLACE 3
The standard tool set is stored in a toolbox placed in the cab
base room in the machine's front direction.
HANDLING GREASE PUMP AND GREASE GUN 3
The grease pump is stored under the center maintenance floor
(right side of machine).
The grease gun is set near the step for getting on or off the
machine at the platform on the right side of the machine.
