MAINTENANCE PROCEDURE MAINTENANCE
4-70
CHECK AIR CONDITIONER COMPRESSOR BELT TENSION, ADJUST 4
There are 2 air conditioner compressors installed to the engine.
When carrying out inspection and adjustment, set to the
engine stop position as follows. Press engine stop switch
(1) installed at the front of the power container on the left
side of the machine, or engine stop switch (2) installed at
the rear of the power container on the right side of the
machine. For details of the method of operating engine
stop switches (1) and (2), see “Stopping in Emergencies
(3-203)“.
Checking
1. Remove cover (3). When bolts (4) and (5) are removed,
the cover will come off.
To Next Page
