MAINTENANCE PROCEDURE MAINTENANCE
4-92
CHANGE OIL IN PTO CASE 4
Parts and oil are at high temperature immediately after the engine is stopped and may cause serious
burns. Wait for the oil temperature to go down before performing this operation.
Park the machine on flat ground and stop the engine. After waiting for more than 30 minutes after stop-
ping the engine, check the oil level.
For details of the method of draining and adding PTO case oil to machines equipped with a service center (option),
see “Method of Draining, Adding PTO Case Oil (6-24)“.
q Oil refill capacity: 36 liter
1. Loosen drain plugs (P) and (Q) under the PTO casing to
drain oil and tighten them after draining.
q When draining the oil, use the drain hose in the tool-
box, install it to oil drain valve (2), and be careful not to
let the drained oil spray out when draining it.
(Drain hose part number: 07287-02618)
To Next Page
