HANDLING JUMP START RECEPTACLE ATTACHMENTS AND OPTIONS
6-36
HANDLING JUMP START RECEPTACLE 6
GENERAL LOCATIONS 6
CONNECTED PROCEDURE OF EXTERNAL POWER SOURCE 6
1. Check that the starting switch key is at OFF position (A).
2. Set the battery isolator switch to OFF position (b).
q For details of the battery isolator switch, see “Battery
Isolator Switch (3-95)“.
(1) Jump start receptacle (2) External power source insertion socket
