COMBINATION OF WORK EQUIPMENT LOADING SHOVEL
7-22
COMBINATION OF WORK EQUIPMENT 7
Depending on the type or combination of work equipment, there is danger that the work equipment may
hit the cab or machine body.
When using unfamiliar work equipment for the first time, check before starting if there is any danger of
interference, and operate with caution.
COMBINATION OF WORK EQUIPMENT 7
Select the combination of boom, arm, and bucket from the combinations shown in the table below.
q For the dimensions of A to F, see the specifications shown in the working range diagram
{: Can be used
: Cannot be used
Work
equipment
Boom 5,900 mm
Arm 4,450 mm
Bucket capacity 11 m³
Bucket width 3,220 mm
Loosen specific gravity of
soil to be handled
2.0
1.8 {
1.6 {
