OPERATION DETAILED CONTROLS AND GAUGES

3-13

Hydraulic oil level monitor

This monitor (5) warns the operator that the hydraulic oil level

has gone down. If there is lack of hydraulic oil, the lamp lights

up red, so check the oil level and add oil.
