DETAILED CONTROLS AND GAUGES OPERATION
3-110
Opening and Closing Caps with Lock
Opening the Cap
1. Insert the key into the key slot.
2. Turn the key clockwise (counterclockwise for type B), align
the key groove with counter mark (3) on the cap, then open
the cap.
(1): Open
(2): Lock
Locking the Cap
1. Turn the cap until tight, then insert the key into the key slot.
2. Turn the starting switch key counterclockwise (clockwise for the B type) and remove the key.
Opening and Closing Cover with Lock
Opening the Cover (Locked Cover)
1. Insert the key into the key slot.
2. Turn the key counterclockwise and open the cover by pull-
ing the cover grip.
(A): Open
(B): Lock
Locking the Cover
1. Close the cover and insert the key into the key slot.
2. Turn the key clockwise and take the key out.
