MAINTENANCE MAINTENANCE PROCEDURE

4-113

REMARK

When the working posture is (2) in the diagram on the right, the

correct oil level on the gauge label is range (a2) at normal tem-

perature and (b2) at high temperature.

10. After changing the hydraulic oil and cleaning the filter element strainer, bleed the air from inside the circuit.
