MAINTENANCE LOADING SHOVEL
7-18
Injector installed location No. Lubrication point
(A)Bucket
(1) F&R bucket connector pin (RH)
(2) F&R bucket connector pin (LH)
(3) Bottom dump cylinder head pin (RH)
(4) Bottom dump cylinder head pin (LH)
(5) Bottom dump cylinder bottom pin (RH)
(6) Bottom dump cylinder bottom pin (LH)
(B)Arm
(7) Arm top pin (RH1)
(8) Arm top pin (LH1)
(9) Arm top pin (RH2)
(10) Arm top pin (LH2)
(11) Arm cylinder head pin (RH)
(12) Arm cylinder head pin (LH)
(13) Bucket cylinder bottom pin (RH)
(14) Bucket cylinder bottom pin (LH)
(15) Boom top pin (RH)
(16) Boom top pin (LH)
(17) Bucket cylinder head (RH)
(18) Bucket cylinder head (LH)
(C)Boom
(19) Boom foot pin (RH)
(20) Boom foot pin (LH)
(21) Arm cylinder bottom pin (RH)
(22) Arm cylinder bottom pin (LH)
(23) Arm cylinder head pin (RH)
(24) Arm cylinder head pin (LH)
(D)Chassis
(25) Boom cylinder bottom pin (RH)
(26) Boom cylinder bottom pin (LH)
