BA 35101/02/ 03 EN – Edition 1.0 * 35101_02_03b330.fm 3-57
Operation
Towing the machine
In order to avoid danger of accidents, the towing vehicle must have enough
tractive power and be fitted with a safe brake system.
☞ Tow away only with a towing bar
➥ See chapter Specifications on page 6-1 for the machine's dimensions
and weights!
☞ Overview of eye hooks for towing the machine – see chapter 1 “Machine
outside view” on page 1-2
☞ If possible, run the engine at idling speed when towing the machine
➥ Steering and braking requires greater effort if the diesel engine breaks
down.
☞ Towing speed => 8 kph max.
☞ Towing distance => 300 m max.
Once towing is over
Enabling the variable displacement pump
☞ Switch over the high pressure relief valves A on the hydraulic pump to drive operation
as follows
• Screw in the high pressure relief valves (A) by 3 – 4 turns and tighten them to 85 Nm
• Mount the protective cap
• Check the drive for correct operation
Fig. 94: Enabling the variable displacement pump
A
