BA 35101/02/ 03 EN – Edition 1.0 * 35101_02_03b510.fm 5-19
Maintenance
5.9 Lubrication work
General safety instructions regarding lubrication work
• Park the wheel loader on level ground and prevent it from rolling away by applying the
parking brake and placing wheel chocks
• Raise the loader unit and secure it with the safety strut on the lift ram
• Stop the engine and remove the ignition key
Lubricate all lubrication points mentioned below with lithium-saponified brand-
name grease
☞ –seeFluids and lubricants on page 5-43
Lubricating the rear axle oscillation-type bearing
The machine has an oscillation-type rear axle. Lubricate the bearing every 20
service hours at the latest.
☞ Lubricate grease nipple A of the oscillation-type bearing
Lubricating the front and rear axle planetary drive bearings
☞ Lubricate grease nipples B (2 x) on each planetary drive bearing every 20 service
hours
Fig. 173: Grease nipples for oscillation-type bearing
A
Fig. 174: Grease nipples on planetary drive bearings
B
