BA 35101/02/ 03 EN – Edition 1.0 * 35101_02_03b610.fm 6-3
Specifications
6.5 Axles
Front axle
Rear axle
Wheel loader models 351-01/351-02/351-03
Design
Planetary steering and drive axle,
rigid screw connection with frame
Differential lock Self-locking differential 45 %
King-pin inclination 0°
Camber 0°
Steering angle 40°
Toe-in 0 mm
Track (distance over hubs) 1400 mm
Wheel loader models 351-01/351-02/351-03
Design Oscillating planetary steering and drive axle
Differential lock Self-locking differential 45 %
King-pin inclination 0°
Camber 0°
Total oscillation angle
1
1. Tyres 12.5-18 (12.5-20)
± 11°
Steering angle 40°
Toe-in 0 mm
Track (distance over hubs) 1400 mm
