12 SDI CONFIG MENU (SER02)
87
12.2.2 Selecting the Color System
To select the color system and the quantization accuracy of the SDI output, follow the
procedure below.
Changing this setting also changes the RATE settings.
Procedure
SDI CONFIG > SDI1 > FORMAT > STRUCTURE
Parameters
422(YCbCr)10-bit / 422(YCbCr)12-bit / 444(RGB)10-bit / 444(RGB)12-bit
Initial value
422(YCbCr)10-bit
12.2.3 Selecting the Frame Frequency
To select the frame (field) frequency of the SDI output, follow the procedure below.
The selectable frequencies depend on SDI FREQUENCY GROUP.
Procedure
SDI CONFIG > SDI1 > FORMAT > RATE
Parameters
59.94P / 29.97P / 23.98P / 29.97PsF / 23.98PsF / 59.94I
(when SDI FREQUENCY GROUP is set to 59.94Hz)
60P / 50P / 30P / 25P / 24P / 30PsF / 25PsF / 24PsF / 60I / 50I
(when SDI FREQUENCY GROUP is set to 60/50Hz)
48P / 47.95P
Initial value
59.94I (when FORMAT SETTING on the SYSTEM CONFIG menu is set to NTSC)
50I (when FORMAT SETTING on the SYSTEM CONFIG menu is set to PAL)
* When SDI FREQUENCY GROUP is set to 59.94Hz, you cannot select "720x 487 SD (59.94I)". When it
is set to 60/50Hz, you can select it.
* When SYSTEM is 4K, all frequencies can be selected, regardless of the setting for SDI FREQUENCY
GROUP.
3 . S D I 1 S T R U C T U R E
} ＊ 4 2 2 ( Y C b C r ) 1 0 - b i t
3 . S D I 1 R A T E
|}
＊ 5 9 . 9 4 I
