2 PRODUCT CONFIGURATION
3
2 PRODUCT CONFIGURATION
2.1 Main Unit
The configuration of the LT4670 instrument is as shown below.
Table 2-1 | Instrument
Model Number
Model Name
Functions
Port
Number
of Ports
LT4670
SYNC GENERATOR
Genlock/CW Input
BNC
2
Analog Black Output
BNC
6
CW/1PPS Output
BNC
1
Word-Clock Output
DIN
1
Silence Output
DIN
1
AES/EBU Output
DIN
1
Ethernet
RJ-45
1
LTC/Remote
D-Sub 26pin
1
Inter-instrument Synchronization
(L-SYNC)
D-Sub 15pin
1
Power Requirements
Power Supply
1
2.2 Hardware Options
The following hardware options can be added to the LT4670.
Hardware options will be added by LEADER or the designated service personnel. Contact your
local LEADER agent.
Table 2-2 | Hardware options
Model Number
Model Name
Functions
Port Added
Number
of Ports
LT4670-SER01
GNSS
GPS / GLONASS / GALILEO /
BDS / QZSS Synchronization
BNC
1
LT4670-SER02
SDI
3G-SDI / HD-SDI / SD-SDI Output
BNC
2
LT4670-SER03
PTP
PTP
SFP/SFP+
2
LT4670-SER11
POWER UNIT
Redundant Power Supply
Power Supply
1
