Leader LT4670 - Setting the SDI Format; Selecting the System

12 SDI CONFIG MENU (SER02)
86
12.2 Setting the SDI Format
Under FORMAT on the SDI1 menu, you can specify settings for the SDI output format.
For the available combinations of "SYSTEM", "STRUCTURE", "RATE", see "3.3.3 LT4670-SER02
(SDI)" and "3.3.6 LT4670-SER21 (4K 3G-Quad Link)".
12.2.1 Selecting the System
To select the system of the SDI output, follow the procedure below. To select an item, use the
▲, ▼, ◀, and ▶ key.
Changing this setting also changes the STRUCTURE And RATE settings.
Procedure
SDI CONFIG > SDI1 > FORMAT > SYSTEM
Parameters
4K(QL)2SI: 3840x2160 3G-A / 4096x2160 3G-A / 3840x2160 3G-B-DL /
4096x2160 3G-B-DL (SER21)
You cannot select this for SDI2 to SDI4.
3G: 1280x 720 3G-A / 1920x1080 3G-A / 1920x1080 3G-B-DL
HD: 1280x 720 HD / 1920x1080 HD
SD: 720x 487 SD / 720x 576 SD
You cannot select this when SDI FREQUENCY GROUP is set to
59.94Hz.
Initial value
1920x1080 HD
1 . S D I 1

F O R M A T ↲
3 . S D I 1 S Y S T E M 4 K ( Q L ) 2 S I
u
} 3 8 4 0 x 2 1 6 0 3 G - A
3 . S D I 1 S Y S T E M 3 G

} 1 2 8 0 x 7 2 0 3 G - A
3 . S D I 1 S Y S T E M H D

| ＊ 1 9 2 0 x 1 0 8 0 H D
3 . S D I 1 S Y S T E M S D

} 7 2 0 x 4 8 7 S D
