8.4.2 Turning BMCA Linkage On and Off (SER03)
If you set ENABLE in the procedure below, the black output is stopped in linkage with BMCA of
the selected PTP. Once the black output is stopped, this menu and the OUTPUT menu are both
changed to DISABLE.
To enable the black output again, set the OUTPUT menu to ENABLE.
Procedure
BLACK CONFIG > BLACK1 > OUTPUT SETTING >
LINKED TO PTP1 BMCA / LINKED TO PTP2 BMCA
Parameters
ENABLE / DISABLE
Initial value
DISABLE
8.5 Settings Shared by Black Outputs
To specify the settings for BLACK2 to be the same as those for BLACK1, select ON by following
the procedure below. In this case, you cannot specify the settings for BLACK2.
Similarly, you can also specify the settings for BLACK3 to BLACK6 to be the same as those for
BLACK1.
Procedure
BLACK CONFIG > BLACK2 > EQUAL TO BLACK1
Parameters
ON / OFF
Initial value
OFF
3 . B L A C K 1 L I N K E D T O P T P 1
□ E N A B L E ■ D I S A B L E
2 . B L A C K 2 E Q U A L T O B L A C K 1
□ O N ■ O F F
