Leader LT4670 - Configuring Timing Data; Selecting the Timing Reference; Adjusting the Timing (Line)

12 SDI CONFIG MENU (SER02)
88
12.3 Configuring Timing Data
Under TIMING on the SDI1 menu, you can adjust the timing of the SDI output relative to the
reference signal.
12.3.1 Selecting the Timing Reference
When the SDI format is set to SD or HD, to select the output timing used as a reference for the
SDI and black outputs, follow the procedure below.
When the SDI format is set to 3G, this is fixed to SERIAL.
Procedure
SDI CONFIG > SDI1 > TIMING > 0H TIMING
Parameters
SERIAL: Signals are output at the timing defined in the signal standard.
LEGACY: Signals are output at the same timing as LEADER's conventional
signal generators.
Initial value
LEGACY
12.3.2 Adjusting the Timing (Line)
To adjust the timing of the SDI output relative to the reference signal at the line level, follow the
procedure below.
The variable range varies depending on the SDI format.
Procedure
SDI CONFIG > SDI1 > TIMING > VERTICAL
Parameters
±1124 [LINE]
Initial value
0 [LINE]
1 . S D I 1

T I M I N G ↲
3 . S D I 1 0 H T I M I N G
□ S E R I A L ■ L E G A C Y
3 . S D I 1 T I M I N G V
0 L I N E
