Leader LT4670 - Configuring Timing Data; Adjusting the Timing (Frame); Adjusting the Timing (Line)

8 BLACK CONFIG MENU
71
Initial value
NTSC BB (when FORMAT SETTING on the SYSTEM CONFIG menu is set to NTSC)
PAL BB (when FORMAT SETTING on the SYSTEM CONFIG menu is set to PAL)
8.2 Configuring Timing Data
Under TIMING on the BLACK1 menu, you can adjust the timing of the black output relative to
the reference signal.
8.2.1 Adjusting the Timing (Frame)
When the black format is set to NTSC or PAL, to adjust the timing of the black output relative to
the reference signal at the frame level, follow the procedure below.
Procedure
BLACK CONFIG > BLACK1 > TIMING > FRAME
Parameters
±5 [FRAME] (when FORMAT is set to NTSC)
±2 [FRAME] (when FORMAT is set to PAL)
Initial value
0 [FRAME]
8.2.2 Adjusting the Timing (Line)
To adjust the timing of the black output relative to the reference signal at the line level, follow
the procedure below.
The variable range varies depending on the black format.
Procedure
BLACK CONFIG > BLACK1 > TIMING > VERTICAL
Parameters
±1124 [LINE]
Initial value
0 [LINE]
1 . B L A C K 1

T I M I N G ↲
3 . B L A C K 1 T I M I N G F
0 F R A M E
3 . B L A C K 1 T I M I N G V
0 L I N E
