9 AUDIO CONFIG MENU
79
9.2.2 Selecting the Resolution
To select the resolution, follow the procedure below.
Procedure
AUDIO CONFIG > SILENCE > SETTING > RESOLUTION
Parameters
20BIT / 24BIT
Initial value
20BIT
9.2.3 Adjusting the Timing
To adjust the timing of the silence output relative to the reference signal in the range of
±1AES/EBU frame, follow the procedure below.
Procedure
AUDIO CONFIG > SILENCE > TIMING
Parameters
±511 [FS]
Initial value
0 [FS]
3 . S I L E N C E R E S O L U T I O N
■ 2 0 B I T □ 2 4 B I T
2 . S I L E N C E T I M I N G
0 [ F S ]
