Leader LT4670 - Setting the Domain; Setting the Communication Mode

13 PTP CONFIG MENU (SER03)
128
13.3.4 Setting the Domain
To set the domain number, follow the procedure below.
Procedure
PTP CONFIG > PTP1 > DETAIL SETTING > DOMAIN
Parameters
0 to 127 (when PROFILE TYPE is set to ST2059)
0 to 255 (when PROFILE TYPE is set to AES67 or GENERAL)
Initial value
127 (when PTP1 is to be configured and PROFILE TYPE is set to ST2059)
0 (when PROFILE TYPE is set to AES67 or GENERAL)
13.3.5 Setting the Communication Mode
To select the communication mode, follow the procedure below.
Procedure
PTP CONFIG > PTP1 > DETAIL SETTING > COMMUNICATION MODE
Parameters
MIXED SMPTE / MIXED SMPTE w/o NE / UNICAST / MULTICAST (when PROFILE TYPE is set to
ST2059)
UNICAST / MULTICAST (when PROFILE TYPE is set to AES67 or GENERAL)
Initial value
MULTICAST
3 . P T P 1 D O M A I N
1 2 7
3 . P T P 1 C O M M U N I C A T I O N
| ＊ M U L T I C A S T
