12 SDI CONFIG MENU (SER02)
85
12 SDI CONFIG MENU (SER02)
The SDI CONFIG menu is used to specify settings related to SDI output.
To display the SDI CONFIG menu, press CONFIG several times until the following menu appears.
On the SDI CONFIG menu, you can specify settings for SDI1 to SDI4 individually. The procedure
below is for SDI1, but the same procedure can also be applied to SDI2 to SDI4. (When one
SER02 is added, only SDI1 and SDI2 are supported.)
When two SER02s are added, 4K 3G-Quad Link can be supported by adding SER21. For the 4K
settings, there is only one output, and you cannot specify settings for SDI2 to SDI4.
12.1 Selecting the Frequency Group
To select the frequency group that can be selected with the frame frequency of the SDI output,
follow the procedure below.
The settings specified here are shared among SDI1 to SDI4.
Procedure
SDI CONFIG > SDI FREQUENCY GROUP
Parameters
59.94Hz: Select the frame frequency from 59.94, 29.97, and 23.98.
60/50Hz: Select the frame frequency from 60, 50, 30, 25, and 24.
Initial value
59.94Hz (when FORMAT SETTING on the SYSTEM CONFIG menu is set to NTSC)
60/50Hz (when FORMAT SETTING on the SYSTEM CONFIG menu is set to PAL)
* When SDI FREQUENCY GROUP is set to 59.94Hz, you cannot select "720x 487 SD (59.94I)". When it
is set to 60/50Hz, you can select it.
* When SYSTEM is 4K, all frequencies can be selected, regardless of the setting you make here.
0 . S D I C O N F I G
|}
u
S D I 1 ↲
1 . S D I F R E Q U E N C Y G R O U P
■ 5 9 . 9 4 H z □ 6 0 / 5 0 H z
