11 CW/1PPS CONFIG MENU
84
11 CW/1PPS CONFIG MENU
The CW/1PPS CONFIG menu is used to specify settings related to the 10MHz CW output and the
1PPS output.
To display the CW/1PPS CONFIG menu, press CONFIG several times until the following menu
appears.
11.1 Switching the Output Signal
To select the signal to output from the CW/1PPS connector on the rear panel, follow the
procedure below.
Procedure
CW/1PPS CONFIG > OUTPUT
Parameters
CW / 1PPS
Initial value
CW
1 . C W / 1 P P S O U T P U T
■ C W □ 1 P P S
1 . C W / 1 P P S O U T P U T
■ C W □ 1 P P S
