Leader LT4670 - CONFIG Menu; REFERENCE Menu

15 STATUS MENU
161
15.3 CONFIG Menu
CONFIG on the STATUS menu shows the instrument settings.
To display the CONFIG menu, press STATUS several times until the following menu appears.
15.3.1 REFERENCE Menu
REFERENCE on the CONFIG menu shows settings related to the reference signal that have been
specified on the REFERENCE CONFIG menu.
Table 15-3 | REFERENCE menu
Item
Description
The reference signal selected with REFERENCE
SOURCE is displayed.
When REFERENCE SOURCE is set to GENLOCK
FMT-MANUAL, the genlock format selected with
GENLOCK FORMAT is displayed.
When REFERENCE SOURCE is set to GENLOCK,
the timing set with GENLOCK TIMING FINE is
displayed.
When REFERENCE SOURCE is set to GNSS, the
satellite selected with GNSS SATELLITE is
displayed. (SER01)
When REFERENCE SOURCE is set to an option
other than INTERNAL, the relock speed
selected with AUTO SETTING or MANUAL
SETTING is displayed.
The time source selected with TIME SOURCE is
displayed.
[ S T A T U S ]
|}
C O N F I G ↲
[ C O N F I G ]
|}
R E F E R E N C E ↲
[ R E F E R E N C E S O U R C E ]
|}
I N T E R N A L
[ G E N L O C K F O R M A T ]
|}
N T S C B B
[ G E N L O C K T I M I N G ]
|}
0 F N
[ G N S S S A T E L L I T E ]
|}
A L L
[ R E C O V E R Y / T R A C K I N G ]
|}
F A S T
[ T I M E S O U R C E ]
|}
I N T E R N A L
