8 BLACK CONFIG MENU
70
8 BLACK CONFIG MENU
The BLACK CONFIG menu is used to specify settings related to the black output.
To display the REFERENCE CONFIG menu, press CONFIG several times until the following menu
appears.
On the BLACK CONFIG menu, you can specify settings for BLACK1 to BLACK6 individually. The
procedure below is for BLACK1, but the same procedure can also be applied to BLACK2 to
BLACK6.
8.1 Selecting the Black Format
To select the black format, follow the procedure below. To select an item, use the ▲, ▼, ◀, and
▶ keys.
The black formats are expressed in terms of the total number of lines, not the number of
effective lines. REF and R represent the field reference pulse, ID represents the field ID, and S
represents setup.
Procedure
BLACK CONFIG > BLACK1 > FORMAT
Parameters
NTSC: NTSC BB / NTSC BB+REF / NTSC BB+ID / NTSC BB+REF+ID /
NTSC BB+SETUP / NTSC BB+S+REF / NTSC BB+S+ID / NTSC
BB+S+R+ID
PAL: PAL BB / PAL BB+REF
COMPONENT: 525/59.94I / 525/59.94P / 625/50I / 625/50P
1125:HD: 1125/60I / 1125/59.94I / 1125/50I / 1125/30P / 1125/29.97P /
1125/25P / 1125/24P / 1125/23.98P / 1125/24PsF /
1125/23.98PsF / 1125/60P / 1125/59.94P / 1125/50P
750:HD: 750/60P / 750/59.94P / 750/50P / 750/30P / 750/29.97P /
750/25P / 750/24P / 750/23.98P
0 . B L A C K C O N F I G
|}
u
B L A C K 1 ↲
2 . B L A C K 1 N T S C
u
} ＊ N T S C B B
2 . B L A C K 1 P A L

} P A L B B
2 . B L A C K 1 C O M P O N E N T

} 5 2 5 / 5 9 . 9 4 I
2 . B L A C K 1 1 1 2 5 : H D

} 1 1 2 5 / 6 0 I
2 . B L A C K 1 7 5 0 : H D

} 7 5 0 / 6 0 P
