Leader LT4670 - Setting Dropped Frames; Setting the Black Output; Turning the Black Output on and off

8 BLACK CONFIG MENU
73
8.3.2 Setting Dropped Frames
To select the dropped frame setting, follow the procedure below.
This setting is valid when the frame frequency of the black output is set to 59.94 or 29.97.
Procedure
BLACK CONFIG > BLACK1 > VITC SETTING > DROP FRAME
Parameters
ON: Dropped frame time code is used.
OFF: Non-dropped frame time code is used.
Initial value
ON
8.4 Setting the Black Output
Under OUTPUT SETTING on the BLACK1 menu, you can specify settings for the black output.
8.4.1 Turning the Black Output On and Off
To turn the black output on and off, follow the procedure below.
Procedure
BLACK CONFIG > BLACK1 > OUTPUT SETTING > OUTPUT
Parameters
ENABLE / DISABLE
Initial value
ENABLE
3 . B L A C K 1 D R O P F R A M E
■ O N □ O F F
1 . B L A C K 1

O U T P U T S E T T I N G ↲
3 . B L A C K 1 O U T P U T
■ E N A B L E □ D I S A B L E
