15.3.2 BLACK Menu
BLACK on the CONFIG menu shows settings related to the black output that have been specified
on the BLACK CONFIG menu.
Table 15-4 | BLACK menu
Item
Description
The BLACK1 format selected with FORMAT is
displayed.
The same holds true for BLACK2 to BLACK6.
The BLACK1 timing set with FRAME, VERTICAL,
and HORIZONTAL is displayed.
The same holds true for BLACK2 to BLACK6.
15.3.3 GNSS Menu (SER01)
GNSS on the CONFIG menu shows settings related to the GNSS option.
Table 15-5 | GNSS menu
Item
Description
The voltage of the power supplied to the GNSS
antenna that has been selected with ANTENNA
POWER on the SYSTEM CONFIG menu is
displayed.
The board ID and the serial number are
displayed.
[ C O N F I G ]
|}
B L A C K ↲
[ B L A C K 1 F O R M A T ]
|}
N T S C B B
[ B L A C K 1 T I M I N G ]
|}
0 F 0 L 0 D
[ C O N F I G ]
|}
G N S S ( S E R 0 1 ) ↲
[ G N S S A N T E N N A ]
|}
O F F
[ S E R 0 1 : 0 0 / 0 0 0 0 0 0 0 ]
|}
