10.6 Setting Dropped Frames
To select the dropped frame setting, follow the procedure below.
This setting is valid when the frame frequency of the LTC output is set to 29.97.
Procedure
LTC CONFIG > LTC OUTPUT > LTC1 > DROP FRAME
Parameters
ON: Dropped frame time code is used.
OFF: Non-dropped frame time code is used.
Initial value
ON
10.7 Settings Shared by LTC Outputs
To specify the settings for LTC2 to be the same as those for LTC1, select ON by following the
procedure below. In this case, you cannot specify the settings for LTC2.
Similarly, you can also specify the settings for LTC3 to be the same as those for LTC1.
Procedure
LTC CONFIG > LTC OUTPUT > LTC2 > EQUAL TO LTC1
Parameters
ON / OFF
Initial value
OFF
3 . L T C 1 D R O P F R A M E
■ O N □ O F F
3 . L T C 2 E Q U A L T O L T C 1
□ O N ■ O F F
