Leader LT4670 - LT4670-SER21 (4 K 3 G-Quad Link)

3 SPECIFICATIONS
26
3.3.6 LT4670-SER21 (4K 3G-Quad Link)
Corresponding Standard
SDI Embedded Audio SMPTE ST 299
SDI Payload ID SMPTE ST 352
SDI Formats and Standards
Table 3-4 | 3G-Quad Link video signal formats and standards (supported only for 4K 2-sample interleave)
Division
Transmission
System
Color
System
Quantization
Frame Frequency/
Scanning
Corresponding
Standard
2 sample
interleave
YC
B
C
R
4:2:2
10bit
3840×2160
60/59.94/50/P
SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160
60/59.94/50/48/47.95/P
SMPTE ST 425-5
SMPTE ST 2048-1
12bit
3840×2160
30/29.97/25/24/23.98/P
SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160
30/29.97/25/24/23.98/P
SMPTE ST 425-5
SMPTE ST 2048-1
RGB 4:4:4
10bit
3840×2160
30/29.97/25/24/23.98/P
SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160
30/29.97/25/24/23.98/P
SMPTE ST 425-5
SMPTE ST 2048-1
12bit
3840×2160
30/29.97/25/24/23.98/P
SMPTE ST 425-5
SMPTE ST 2036-1
4096×2160
30/29.97/25/24/23.98/P
SMPTE ST 425-5
SMPTE ST 2048-1
SDI Video Output
SDI Signal
Bit Rate
3G (QL) 2.970Gbps, 2.970/1.001Gbps
Timing Adjustment
Adjustment Range Entire frame
Adjustment Unit
V Lines
H Clocks (148.5 MHz, 148.5/1.001 MHz)
Test Patterns 100% color bar, 75% color bar, multiformat color bar
(ARIB STD-B28, pattern 2 area can be set to 100%
white, 75% white, or +I), check field, flat field white
100%, white 50%, black 0%, red 100%, green 100%,
blue 100%
