18 APPENDIX
198
18.1.6 SDI CONFIG Menu (SER02)
Table 18-6 | SDI CONFIG menu
Setting
Value
Initial Value
SDI FREQUENCY GROUP
59.94Hz / 60/50Hz
59.94Hz (NTSC)
60/50Hz (PAL)
SDI* SYSTEM
3840x2160 3G-A / 4096x2160 3G-A / 3840x2160 3G-B-DL /
4096x2160 3G-B-DL /
1280x 720 3G-A / 1920x1080 3G-A / 1920x1080 3G-B-DL /
1280x 720 HD / 1920x1080 HD /
720x 487 SD / 720x 576 SD
1920x1080 HD
SDI* STRUCTURE
422(YCbCr)10-bit / 422(YCbCr)12-bit / 444(RGB)10-bit /
444(RGB)12-bit
422(YCbCr)
10-bit
SDI* RATE
59.94P / 29.97P / 23.98P / 29.97PsF / 23.98PsF / 59.94I /
60P / 50P / 30P / 25P / 24P / 30PsF / 25PsF / 24PsF / 60I / 50I /
48P / 47.95P
59.94I (NTSC)
50I (PAL)
SDI* 0H TIMING
SERIAL / LEGACY
LEGACY
SDI* TIMING V
±1124
0
SDI* TIMING H
±4124
0
SDI* PATTERN
100% / 75% / MULTI 100% / MULTI 75% / MULTI (+I) / SMPTE /
EBU / BBC /
FLAT FIELD 100% / FLAT FIELD 50% / FLAT FIELD 0% / RED
FIELD 100% / GREEN FIELD 100% / BLUE FIELD 100% /
CHECK FIELD
100%
SDI* COMPONENT
ON / OFF
All ON
SDI* SAFETY AREA
ON / OFF
All OFF
SDI* SCROLL
ON / OFF
OFF
SDI* SCROLL V-SPEED
±256
0
SDI* SCROLL H-SPEED
±256
0
SDI* PATTERN CHANGE
ON / OFF
OFF
SDI* PATTERN CHG SPEED
+1 - +255
+1
SDI* ID CHARACTER
ON / OFF
OFF
SDI* ID SET
◀ !"#$%&'()*+,-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRS
TUVWXYZ[\]^_→← (up to 20 characters)
LT4670◀
SDI* ID V-POSI
0 - 100
0
SDI* ID H-POSI
0 - 100
0
SDI* ID SIZE
x1 / x2 / x4 / x8
x1
SDI* ID LEVEL
100% / 75%
100%
SDI* ID BLINK
ON / OFF
OFF
SDI* ID BLINK ON TIME
1 - 9
1
SDI* ID BLINK OFF TIME
1 - 9
1
SDI* ID SCROLL
ON / OFF
OFF
SDI* ID SCROLL SPEED
±256
0
SDI* MOVING BOX
ON / OFF
OFF
SDI* BOX COLOR
WHITE / YELLOW / CYAN / GREEN / BLUE / RED / MAGENTA /
BLACK
WHITE
