13.3.6 Selecting the Desired Announce Message Transmission Interval
When COMMUNICATION MODE is set to UNICAST, to select the interval at which you want the
announce message to be transmitted to the destination leader, follow the procedure below.
Select an interval shorter than ANNOUNCE REQD INT.
Procedure
PTP CONFIG > PTP1 > DETAIL SETTING > ANNOUNCE DESIR INT
Parameters
0.125s / 0.25s / 0.5s / 1s / 2s (when PROFILE TYPE is set to ST2059)
1s / 2s / 4s / 8s / 16s (when PROFILE TYPE is set to AES67)
0.125s / 0.25s / 0.5s / 1s / 2s / 4s / 8s / 16s (when PROFILE TYPE is set to GENERAL)
Initial value
0.25s (when PROFILE TYPE is set to ST2059)
2s (when PROFILE TYPE is set to AES67 or GENERAL)
13.3.7 Selecting the Announce Message Reception Interval
When COMMUNICATION MODE is set to UNICAST, to set the minimum interval at which the
follower can receive the announce message, follow the procedure below.
Procedure
PTP CONFIG > PTP1 > DETAIL SETTING > ANNOUNCE REQD INT
Parameters
0.125s / 0.25s / 0.5s / 1s / 2s (when PROFILE TYPE is set to ST2059)
1s / 2s / 4s / 8s / 16s (when PROFILE TYPE is set to AES67)
0.125s / 0.25s / 0.5s / 1s / 2s / 4s / 8s / 16s (when PROFILE TYPE is set to GENERAL)
Initial value
2s (when PROFILE TYPE is set to ST2059)
16s (when PROFILE TYPE is set to AES67 or GENERAL)
3 . P T P 1 A N C D E S I R I N T
|}
＊ 0 . 2 5 s 4 H z
3 . P T P 1 A N C R E Q D I N T
| ＊ 2 s 0 . 5 H z
