9 AUDIO CONFIG MENU
77
9.1.6 Selecting the Pre-emphasis Mode
To select the pre-emphasis mode, follow the procedure below.
Procedure
AUDIO CONFIG > AES/EBU > SETTING > EMPHASIS
Parameters
50/15 / CCITT / OFF
Initial value
OFF
9.1.7 Turning Time Code Insertion On and Off
To turn time code insertion on and off, follow the procedure below.
The time code selected with TIME SOURCE on the REFERENCE CONFIG menu is used.
Procedure
AUDIO CONFIG > AES/EBU > SETTING > TIMECODE
Parameters
ON / OFF
Initial value
OFF
9.1.8 Adjusting the Timing
To adjust the timing of the AES/EBU output relative to the reference signal in the range of
±1AES/EBU frame, follow the procedure below.
Procedure
AUDIO CONFIG > AES/EBU > TIMING
Parameters
±511 [FS]
Initial value
0 [FS]
3 . A E S / E B U E M P H A S I S
□ 5 0 / 1 5 □ C C I T T ■ O F F
3 . A E S / E B U T I M E C O D E
□ O N ■ O F F
2 . A E S / E B U T I M I N G
0 [ F S ]
