Leader LT4670 - Selecting the Desired Sync Message Transmission Interval; Selecting the Sync Message Reception Interval

13 PTP CONFIG MENU (SER03)
130
13.3.8 Selecting the Desired Sync Message Transmission Interval
When COMMUNICATION MODE is set to UNICAST, to select the interval at which you want the
sync message to be transmitted to the destination leader, follow the procedure below.
Select an interval shorter than SYNC REQD INT.
Procedure
PTP CONFIG > PTP1 > DETAIL SETTING > SYNC DESIR INT
Parameters
0.0078s / 0.015s / 0.0312s / 0.0625s / 0.125s / 0.25s / 0.5s (when PROFILE TYPE is set to
ST2059)
0.0625s / 0.125s / 0.25s / 0.5s / 1s / 2s (when PROFILE TYPE is set to AES67)
0.0078s / 0.015s / 0.0312s / 0.0625s / 0.125s / 0.25s / 0.5s / 1s / 2s / 4s / 8s (when PROFILE
TYPE is set to GENERAL)
Initial value
0.125s (when PROFILE TYPE is set to ST2059)
1s (when PROFILE TYPE is set to AES67)
2s (when PROFILE TYPE is set to GENERAL)
13.3.9 Selecting the Sync Message Reception Interval
When COMMUNICATION MODE is set to UNICAST, to select the minimum interval at which the
follower can receive the sync message, follow the procedure below.
Procedure
PTP CONFIG > PTP1 > DETAIL SETTING > SYNC REQD INT
Parameters
0.0078s / 0.015s / 0.0312s / 0.0625s / 0.125s / 0.25s / 0.5s (when PROFILE TYPE is set to
ST2059)
0.0625s / 0.125s / 0.25s / 0.5s / 1s / 2s (when PROFILE TYPE is set to AES67)
0.0078s / 0.015s / 0.0312s / 0.0625s / 0.125s / 0.25s / 0.5s / 1s / 2s / 4s / 8s (when PROFILE
TYPE is set to GENERAL)
Initial value
0.5s (when PROFILE TYPE is set to ST2059)
2s (when PROFILE TYPE is set to AES67)
8s (when PROFILE TYPE is set to GENERAL)
3 . P T P 1 S Y N D E S I R I N T
|}
＊ 0 . 1 2 5 s 8 H z
3 . P T P 1 S Y N R E Q D I N T
| ＊ 0 . 5 s 2 H z
