Leader LT4670 - AUDIO CONFIG Menu; LTC CONFIG Menu; CW;1 PPS CONFIG Menu

18 APPENDIX
197
Setting
Value
Initial Value
BLACK* DROP FRAME
ON / OFF
ON
BLACK* OUTPUT
ENABLE / DISABLE
ENABLE
BLACK* LINKED TO PTP*
ENABLE / DISABLE
DISABLE
BLACK2 EQUAL TO BLACK1
ON / OFF
OFF
BLACK3 EQUAL TO BLACK1
ON / OFF
OFF
BLACK4 EQUAL TO BLACK1
ON / OFF
OFF
BLACK5 EQUAL TO BLACK1
ON / OFF
OFF
BLACK6 EQUAL TO BLACK1
ON / OFF
OFF
18.1.3 AUDIO CONFIG Menu
Table 18-3 | AUDIO CONFIG menu
Setting
Value
Initial Value
AES/EBU CH* FREQ
SILENCE / 400Hz / 800Hz / 1kHz
1kHz
AES/EBU CH* LEVEL
-60 - 0
-20
AES/EBU CH* CLICK
OFF / 1sec / 2sec / 4sec
OFF
CH2 EQUAL TO CH1
ON / OFF
OFF
AES/EBU RESOLUTION
20BIT / 24BIT
20BIT
AES/EBU EMPHASIS
50/15 / CCITT / OFF
OFF
AES/EBU TIMECODE
ON / OFF
OFF
AES/EBU TIMING
±511
0
LIPSYNC(SYNC TO SDI1)
ON / OFF
OFF
EQUAL TO AES/EBU
ON / OFF
OFF
SILENCE RESOLUTION
20BIT / 24BIT
20BIT
SILENCE TIMING
±511
0
WCLK TIMING
±511
0
18.1.4 LTC CONFIG Menu
Table 18-4 | LTC CONFIG menu
Setting
Value
Initial Value
LTC*
ON / OFF
OFF
LTC* FORMAT
30 / 29.97 / 25 / 24 / 23.98
29.97 (NTSC)
25 (PAL)
LTC* TIMING FRAME
±29
0
LTC* TIMING BIT
±39
0
LTC* OFFSET
±23:59:59
+00:00:00
LTC* DROP FRAME
ON / OFF
ON
LTC2 EQUAL TO LTC1
ON / OFF
OFF
LTC3 EQUAL TO LTC1
ON / OFF
OFF
18.1.5 CW/1PPS CONFIG Menu
Table 18-5 | CW/1PPS CONFIG menu
Setting
Value
Initial Value
CW/1PPS OUTPUT
CW / 1PPS
CW
