8 BLACK CONFIG MENU
72
8.2.3 Adjusting the Timing (Dot)
To adjust the timing of the black output relative to the reference signal at the dot level, follow
the procedure below. At the lower right of the screen, the value in dots converted to time is
displayed.
The variable range varies depending on the black format.
Procedure
BLACK CONFIG > BLACK1 > TIMING > HORIZONTAL
Parameters
±4124 [DOT]
Initial value
0 [DOT]
8.3 Setting the Time Code
Under VITC SETTING on the BLACK1 menu, you can specify settings for the time code to insert
into the black output.
This menu appears when the black format is set to NTSC or PAL.
8.3.1 Turning Time Code Insertion On and Off
To turn time code insertion on and off, follow the procedure below.
The time code selected with TIME SOURCE on the REFERENCE CONFIG menu is used.
Procedure
BLACK CONFIG > BLACK1 > VITC SETTING > VITC
Parameters
ON / OFF
Initial value
OFF
3 . B L A C K 1 T I M I N G H
0 D O T 0 . 0 0 0 0 μ s
1 . B L A C K 1

V I T C S E T T I N G ↲
3 . B L A C K 1 V I T C
□ O N ■ O F F
