14 SYSTEM CONFIG MENU
140
14.3.2 Setting the IP Address
To set the IP address, follow the procedure below.
Procedure
SYSTEM CONFIG > NETWORK > ETHERNET > IP ADDRESS
Parameters
000.000.000.000 - 255.255.255.255
Initial value
192.168.000.001
14.3.3 Setting the Subnet Mask
To set the subnet mask, follow the procedure below.
Procedure
SYSTEM CONFIG > NETWORK > ETHERNET > SUBNET MASK
Parameters
000.000.000.000 - 255.255.255.255
Initial value
255.255.255.000
14.3.4 Setting the Default Gateway
To set the default gateway, follow the procedure below.
Procedure
SYSTEM CONFIG > NETWORK > ETHERNET > DEFAULT GATEWAY
Parameters
000.000.000.000 - 255.255.255.255
Initial value
000.000.000.000
3 . I P A D D R E S S
1 9 2 . 1 6 8 . 0 0 0 . 0 0 1
3 . S U B N E T M A S K
2 5 5 . 2 5 5 . 2 5 5 . 0 0 0
3 . D E F A U L T G A T E W A Y
0 0 0 . 0 0 0 . 0 0 0 . 0 0 0
