12 SDI CONFIG MENU (SER02)
111
12.12.5 Selecting the Time Code Level
To select the time code intensity level, follow the procedure below.
Procedure
SDI CONFIG > SDI1 > VIDEO > TIMECODE > LEVEL
Parameters
100% / 75%
Initial value
100%
12.13 Turning Lip Sync On and Off
To turn lip sync pattern on and off, follow the procedure below.
When it is turned on, the instrument outputs lip sync patterns. Combining these with our lip-
sync-compatible waveform monitor makes it possible to measure the offset between the video
signal and the audio signal that occurs in the transfer route for each channel. For details, see
the instruction manual of the waveform monitor.
Procedure
SDI CONFIG > SDI1 > VIDEO > LIPSYNC > ON/OFF
Parameters
ON/OFF
Initial value
OFF
4 . S D I 1 T I M E C O D E L E V E L
■ 1 0 0 % □ 7 5 %
4 . S D I 1 L I P S Y N C
□ O N ■ O F F
