10 LTC CONFIG MENU
81
10 LTC CONFIG MENU
The LTC CONFIG menu is used to specify settings related to LTC output.
To display the LTC CONFIG menu, press CONFIG several times until the following menu appears.
On the LTC CONFIG menu, you can specify settings for LTC1 to LTC3 individually. The procedure
below is for LTC1, but the same procedure can also be applied to LTC2 and LTC3.
10.1 Turning the LTC Output On and Off
To turn the LTC output on and off, follow the procedure below.
Procedure
LTC CONFIG > LTC OUTPUT > LTC1 > ON/OFF
Parameters
ON / OFF
Initial value
OFF
10.2 Selecting the LTC Format
To select the LTC format, follow the procedure below.
Procedure
LTC CONFIG > LTC OUTPUT > LTC1 > FORMAT
Parameters
30 / 29.97 / 25 / 24 / 23.98 fps
Initial value
29.97 fps (when FORMAT SETTING on the SYSTEM CONFIG menu is set to NTSC)
25 fps (when FORMAT SETTING on the SYSTEM CONFIG menu is set to PAL)
0 . L T C C O N F I G
|}
L T C O U T P U T ↲
3 . L T C 1
□ O N ■ O F F
3 . L T C 1 F O R M A T
} ＊ 2 9 . 9 7 f p s
