Leader LT4670 - Settings Shared by Channels; Settings Shared by Groups

12 SDI CONFIG MENU (SER02)
116
12.14.7 Settings Shared by Channels
To specify the settings for CH2 (frequency, level, and click sound) to be the same as those for
CH1, select ON by following the procedure below. In this case, you cannot specify the settings
for CH2.
The same holds true for other channels.
Procedure
SDI CONFIG > SDI1 > EMBEDDED AUDIO
> G1 > CH2 - 4 > EQUAL TO CH1
> G2 > CH6 - 8 > EQUAL TO CH5
> G3 > CH10 - 12 > EQUAL TO CH9
> G4 > CH14 - 16 > EQUAL TO CH13
Parameters
ON / OFF
Initial value
OFF
12.14.8 Settings Shared by Groups
To specify the settings for group 2 to be the same as those for group 1, select ON by following
the procedure below. In this case, you cannot specify the settings for group 2.
The same holds true for group 3 and group 4.
Procedure
SDI CONFIG > SDI1 > EMBEDDED AUDIO
> G2 > EQUAL TO G1
> G3 > EQUAL TO G1
> G4 > EQUAL TO G3
Parameters
ON / OFF
Initial value
OFF
5 . S D I 1 G 1 / C H 2 E Q U A L C H 1
□ O N ■ O F F
4 . S D I 1 G 2 E Q U A L T O G 1
□ O N ■ O F F
