Leader LT4670 - Copying ID Characters from the Instrument to a USB Memory Device; Clearing ID Characters

12 SDI CONFIG MENU (SER02)
102
12.9.15 Copying ID Characters from the Instrument to a USB Memory Device
To copy ID characters in a dedicated format (.id) from the instrument to a USB memory device,
follow the procedure below. This feature is useful when you want to use multiple instruments
with the same settings. (Save the ID characters in the instrument in advance by using the
STORE menu.)
This setting appears when a USB memory device is connected.
Procedure
SDI CONFIG > SDI1 > VIDEO > ID CHARACTER > COPY INT→USB
To copy ID characters, follow the procedure below.
1. Select the copy source in the instrument.
Select ALL or from INT1 to INT4.
2. Select OK.
● USB Memory Device Structure
ID characters are copied to the ID folder of the USB memory device.
The date and time of the file will be the date and time selected with TIME SOURCE on the
REFERENCE CONFIG menu.
■ USB memory device
┗ ■ LT4670_USER
┗ ■ ID
┗ ■ ****.id
12.9.16 Clearing ID Characters
To clear ID characters that have been saved in the instrument, follow the procedure below.
Procedure
SDI CONFIG > SDI1 > VIDEO > ID CHARACTER > DELETE
To clear ID characters, follow the procedure below.
1. Select the ID characters you want to clear.
Select ALL or from INT1 to INT4.
2. Select OK.
4 . S D I 1 I D C O P Y I N T → U S B
} A L L
5 . S D I 1 I D C O P Y I N T → U S B
■ O K □ C A N C E L
4 . S D I 1 I D D E L E T E
} A L L
5 . S D I 1 I D D E L E T E
■ O K □ C A N C E L
