Leader LT4670 - Setting the Genlock Timing; Selecting the Satellite (SER01)

7 REFERENCE CONFIG MENU
65
7.3 Setting the Genlock Timing
When REFERENCE SOURCE is set to GENLOCK, you can collectively adjust the timing of the
output signals (ANALOG BLACK OUT, 3G SDI OUT, AES/EBU, SILENCE, WCLK, and LTC) relative
to the reference signal. (You can also adjust them individually.)
One step is approximately 0.5 ns, which covers a 1-dot cycle.
Procedure
REFERENCE CONFIG > GENLOCK TIMING FINE
Parameters
±100
Initial value
0
7.4 Selecting the Satellite (SER01)
When REFERENCE SOURCE is set to GNSS, to select the satellite, follow the procedure below.
Leave this set to ALL under standard operating circumstances.
Procedure
REFERENCE CONFIG > GNSS SATELLITE
Parameters
ALL / GPS / GLONASS / GALILEO / BDS / GPS+QZSS
Initial value
ALL
1 . G E N L O C K T I M I N G F I N E
F I N E : 0
1 . G N S S S A T E L L I T E
} ＊ A L L
