14 SYSTEM CONFIG MENU
134
14 SYSTEM CONFIG MENU
The SYSTEM CONFIG menu is used to specify settings related to the instrument.
To display the SYSTEM CONFIG menu, press CONFIG several times until the following menu
appears.
These settings are not stored to presets.
14.1 Setting the Backlight
To set the backlight, follow the procedure below.
Procedure
SYSTEM CONFIG > LCD BACKLIGHT
Parameters
ON: The backlight is on at all times.
AUTO OFF: The backlight turns off if none of the keys are used for 30
seconds. It turns back on when a key is used.
OFF: The backlight is off at all times.
Initial value
ON
14.2 Configuring Presets
Under PRESET on the SYSTEM CONFIG menu, you can configure presets.
A preset is a collection of instrument settings that are registered. It can be recalled
automatically when the instrument starts.
The following items are not stored in preset settings.
・SDI CONFIG menu: ID CHARACTER (INT1 to INT4)
・SYSTEM CONFIG menu
0 . S Y S T E M C O N F I G
|}
u
L C D B A C K L I G H T ↲
1 . L C D B A C K L I G H T
■ O N □ A U T O O F F □ O F F
0 . S Y S T E M C O N F I G
|}

P R E S E T ↲
