14 SYSTEM CONFIG MENU
148
14.6 Configuring the PTP Settings (SER03)
Under PTP OPTION on the SYSTEM CONFIG menu, you can specify settings related to PTP.
14.6.1 Setting the IP Address
To set the IP address of the selected PTP, follow the procedure below.
Procedure
SYSTEM CONFIG > PTP OPTION > PTP1 / PTP2 > IP ADDRESS
Parameters
000.000.000.000 - 255.255.255.255
Initial value
192.168.000.001
14.6.2 Setting the Subnet Mask
To set the subnet mask of the selected PTP, follow the procedure below.
Procedure
SYSTEM CONFIG > PTP OPTION > PTP1 / PTP2 > SUBNET MASK
Parameters
000.000.000.000 - 255.255.255.255
Initial value
255.255.255.000
0 . S Y S T E M C O N F I G
|}

P T P O P T I O N ↲
3 . P T P 1 I P A D D R E S S
1 9 2 . 1 6 8 . 0 0 0 . 0 0 1
3 . P T P 1 S U B N E T M A S K
2 5 5 . 2 5 5 . 2 5 5 . 0 0 0
