9 AUDIO CONFIG MENU
75
9 AUDIO CONFIG MENU
The AUDIO CONFIG menu is used to specify settings related to the AES/EBU output, silence
output, and word-clock output.
To display the AUDIO CONFIG menu, press CONFIG several times until the following menu
appears.
9.1 Setting the AES/EBU Output
Under AES/EBU on the AUDIO CONFIG menu, you can specify settings for the AES/EBU output.
9.1.1 Selecting the Frequency
To select the frequency of the selected channel, follow the procedure below.
Procedure
AUDIO CONFIG > AES/EBU > SETTING > CH1 / CH2 > FREQ
Parameters
SILENCE / 400Hz / 800Hz / 1kHz
Initial value
1kHz
9.1.2 Setting the Level
To set the level of the selected channel, follow the procedure below.
Procedure
AUDIO CONFIG > AES/EBU > SETTING > CH1 / CH2 > LEVEL
Parameters
-60 - 0 [dBFS]
Initial value
-20 [dBFS]
0 . A U D I O C O N F I G
|}
u
A E S / E B U ↲
0 . A U D I O C O N F I G
|}
u
A E S / E B U ↲
4 . A E S / E B U C H 1 F R E Q
| ＊ 1 k H z
4 . A E S / E B U C H 1 L E V E L
- 2 0 [ d B F S ]
