14 SYSTEM CONFIG MENU
149
14.6.3 Setting the Gateway
To set the gateway of the selected PTP, follow the procedure below.
Procedure
SYSTEM CONFIG > PTP OPTION > PTP1 / PTP2 > DEFAULT GATEWAY
Parameters
000.000.000.000 - 255.255.255.255
Initial value
192.168.000.254
14.6.4 Configuring SFP
To select the type of the SFP of the selected PTP, follow the procedure below.
Make the selection with the module connected with a cable.
Connection may not be established if the module is inserted or the cable is connected after
making the selection.
Procedure
SYSTEM CONFIG > PTP OPTION > PTP1 / PTP2 >SFP/SFP+
Parameters
SFP / SFP+
Initial value
SFP+
14.6.5 Setting Port Mirroring
To select the settings for port mirroring, follow the procedure below.
Procedure
SYSTEM CONFIG > PTP OPTION > PTP PORT MIRRORING
Parameters
OFF: Port mirroring is not performed.
PTP1 to PTP2: PTP1 packets are copied and transmitted to PTP2.
PTP2 to PTP1: PTP2 packets are copied and transmitted to PTP1.
Initial value
OFF
3 . P T P 1 G A T E W A Y
1 9 2 . 1 6 8 . 0 0 0 . 2 5 4
3 . P T P 1 S F P / S F P ＋
| ＊ S F P ＋
2 . P T P P O R T M I R R O R I N G
} ＊ O F F
