13 PTP CONFIG MENU (SER03)
123
13.2.8 Setting the Announce Message Transmission Interval
To select the announce message transmission interval, follow the procedure below.
This menu item is not displayed when COMMUNICATION MODE is set to UNICAST.
Procedure
PTP CONFIG > PTP1 > DETAIL SETTING > ANNOUNCE INTERVAL
Parameters
0.125s / 0.25s / 0.5s / 1s / 2s (when PROFILE TYPE is set to ST2059)
1s / 2s / 4s / 8s / 16s (when PROFILE TYPE is set to AES67)
0.125s / 0.25s / 0.5s / 1s / 2s / 4s / 8s / 16s (when PROFILE TYPE is set to GENERAL)
Initial value
0.25s (when PROFILE TYPE is set to ST2059)
2s (when PROFILE TYPE is set to AES67 or GENERAL)
13.2.9 Setting the Sync Message Transmission Interval
To select the sync message transmission interval, follow the procedure below.
This menu item is not displayed when COMMUNICATION MODE is set to UNICAST.
Procedure
PTP CONFIG > PTP1 > DETAIL SETTING > SYNC INTERVAL
Parameters
0.0078s / 0.015s / 0.0312s / 0.0625s / 0.125s / 0.25s / 0.5s
(when PROFILE TYPE is set to ST2059)
0.0625s / 0.125s / 0.25s / 0.5s / 1s (when PROFILE TYPE is set to AES67)
0.125s / 0.25s / 0.5s / 1s / 2s / 4s / 8s / 16s (when PROFILE TYPE is set to GENERAL)
Initial value
0.125s (when PROFILE TYPE is set to ST2059 or AES67)
1s (when PROFILE TYPE is set to GENERAL)
3 . P T P 1 A N N O U N C E I N T
|}
＊ 0 . 2 5 s 4 H z
3 . P T P 1 S Y N C I N T E R V A L
|}
＊ 0 . 1 2 5 s 8 H z
