15 STATUS MENU
160
Item
Description
When REFERENCE SOURCE is set to PTP, the
phase difference from the leader is displayed.
(SER03)
When TIME SOURCE is set to NTP, GNSS
(SER01), or PTP (SER03), the Coordinated
Universal Time loaded from TIME SOURCE is
displayed.
The internal clock of the instrument is
displayed.
The date and time selected with TIME SOURCE
on the REFERENCE CONFIG menu is displayed.
When TIME SOURCE is set to LTC or VITC, the
time, transmission rate, and whether there is a
dropped frame (DF) are displayed.
When TIME SOURCE is set to LTC or VITC, the
date and time, transmission rate, whether
there is a dropped frame (DF), and time zone
(TZ) are displayed.
If the time cannot be acquired, "----------" is
displayed.
When PTP1 MODE on the PTP CONFIG menu is
set to ENABLE LEADER, the output status is
displayed. (SER03)
When PTP2 MODE on the PTP CONFIG menu is
set to ENABLE LEADER, the output status is
displayed. (SER03)
[ P T P 1 P H A S E ]
|}
1 . 2 3 4 n s
[ U T C T I M E ]
|}
2 0 2 3 / 0 4 / 0 1 1 2 : 3 4 : 5 6
[ L O C A L T I M E ]
|}
2 0 2 3 / 0 4 / 0 1 1 2 : 3 4 : 5 6
[ T I M E S O U R C E ] I N T E R N A L
|}
2 0 2 3 / 0 4 / 0 1 1 2 : 3 4 : 5 6
[ T I M E S O U R C E ] L T C
|}
1 2 : 3 4 : 5 6 2 9 . 9 7 f p s D F
[ T I M E S O U R C E ] L T C S T 3 0 9
|}
2 0 2 3 / 0 4 / 0 1 1 2 : 3 4 : 5 6
[ T I M E S O U R C E ] L T C S T 3 0 9
|}
2 9 . 9 7 f p s D F T Z : U T C + 0 9 ： 0 0
[ T I M E S O U R C E ] G N S S
|}
- - - - - - - - - -
[ P T P O U T P U T ] P T P 1
|}
L E A D E R
[ P T P O U T P U T ] P T P 2
|}
L E A D E R
