3 SPECIFICATIONS
6
AES/EBU Signal Output
This option can output a 48 kHz AES/EBU signal synchronized with video signals. (AES/EBU
connector)
It is also equipped with a AES/EBU signal output compatible with DARS. (SILENCE connector)
CW/1PPS Output
The CW/1PPS output can output 10 MHz CW or 1PPS, whichever is selected.
Time Code I/O
The time code generator can run in free run mode based on internal time information. Based on
the NTP server, LTC, VITC, GNSS (SER01), or PTP (SER03) time information, it can embed the
LTC3 system output and analog video sync signal output in VITC, as well as the SDI (SER02)
output in ATC (LTC/VITC).
LTC I/O
The LTC has three independent outputs for an input. An offset time can be set for each output
with respect to the frame rate and reference time.
Remote Connector
The remote connector can be used to load presets and transmit two alarm outputs.
Inter-instrument Synchronization Control (L-SYNC)
In a redundant system, the time can be synchronized by connecting the main and backup
devices that are synchronized with the same analog video sync signal via L-SYNC.
Real Time Clock
The real time clock is backed up by a battery. There is no need to reset the clock even when the
power is turned off and then back on.
Ethernet
Control is exerted based on the SNMP (future support). When an error is detected, a TRAP is
issued. Also, this instrument can be controlled using the HTTPS (future support), HTTP, and
REST-API (future support).
When connected to an NTP server as an NTP client, the instrument can be used for internal
clock synchronization or as an NTP server.
Preset Memory Function
Up to 10 presets can be saved. Convenient registered presets can be recalled during operation.
The LT4670 can be started with the same settings every time.
