3 SPECIFICATIONS
12
Corresponding Standard
Analog Video Sync Signal
NTSC Black Burst Signal SMPTE ST 170, SMPTE ST 318, SMPTE RP 154
PAL Black Burst Signal ITU-R BT 1700, EBU N14
HD Tri-level Sync Signal SMPTE ST 240, SMPTE ST 274, SMPTE ST 296
AES/EBU Signal ANSI S4.40, AES3-2009, AES11-2009, SMPTE ST 276
LTC Signal SMPTE 12M-1
Phase Management SMPTE ST 2059-1
I/O Connectors
Genlock Input Connector
Connector 2 BNC connectors
Input Signal Analog composite sync signal
HD Tri-level Sync Signal Analog composite sync signal
Format Loop-through
Input Impedance 47 kΩ
Maximum Input Voltage ±5 V (DC + peak AC)
Operating Input Level Range ±6 dB
External Lock Range ±5 ppm
Jitter 1 ns (when genlock is in use)
10 MHz CW Input Connector
Connector 1 BNC connector (used in combination with the genlock
input connector)
Input Impedance 47 kΩ (used with 50 Ω terminated to the loop-through)
Input Signal Level 0.5 - 1 Vrms (50 Ω termination)
Input Signal Frequency 10 MHz
Locking Frequency Range ±5 ppm
10 MHz CW/1PPS Output Connectors
Connector 1 BNC connector (used in combination with 10 MHz CW
and 1PPS)
Output Amplitude Signal Level
10 MHz CW 2 Vp-p ± 20% (1 Vrms) for square waves; 50 Ω
termination
1PPS 4.8 ± 0.5 V (no termination, high level)
2.4 ± 0.25 V (50 Ω termination, high level)
Output Impedance 50 Ω unbalanced
Output Signal Frequency 10 MHz/1PPS
