3 SPECIFICATIONS
17
AES/EBU Digital Audio Output
Timing Adjustment
Adjustment Range ±1 AES/EBU frame (±511)
Adjustment Unit In units of 512 fs (24.576 MHz)
Sampling Frequency 48 kHz sampling (synced with the video signal)
Resolution 20 bits, 24 bits
Pre-emphasis OFF, 50/15, CCITT (only the CS bit is switched)
Frequency SILENCE, 400 Hz, 800 Hz, 1 kHz
Level -60 – 0 dBFS (in units of 1 dBFS)
Audio Click OFF, 1, 2, 4 sec
Lip Sync Synchronization with SDI-1
Sampling Clock Accuracy Grade 2 (±10 ppm)
* The frequency, level, and audio click can be set for each channel.
AES/EBU Silence Output
Timing Adjustment
Adjustment Range ±1 AES/EBU frame (±511)
Adjustment Unit In units of 512 fs (24.576 MHz)
Sampling Frequency 48 kHz sampling (synced with the video signal)
Resolution 20 bits, 24 bits
Pre-emphasis OFF
Frequency SILENCE
Level MUTE
Sampling Clock Accuracy Grade 2 (±10 ppm)
* Supports DARS.
* When EQUAL TO AES/EBU is set to on, the same signal as the AES/EBU digital audio signal is output.
Word-Clock Output
Timing Adjustment
Adjustment Range ±1 AES/EBU frame (±511)
Adjustment Unit In units of 512 fs (24.576 MHz)
Time Code Function
Reference Time Internal / NTP / LTC / VITC / GNSS (SER01) / PTP
(SER03)
Frame Rate 30 / 29.97 / 25 / 24 / 23.98 Hz
Dropped Frame Mode On/Off
JAM SYNC
Application Setting Set the application time with a timer.
ATC Setting
LTC Insertion Setting On/Off
VITC Insertion Setting On/Off
LTC Setting
Output Setting On/Off
