Preparations
101
 Mount one of the following PTO shaft
ends to the tractor:
 Cardan shaft end is marked with the
tractor symbol
 Wide-angle joint
 Mount opposite PTO shaft end to the
device.
Shortening a non-telescopic PTO shaft.
 Pull both PTO shaft halves apart.
 Keep both PTO shaft halves at the shor-
test distance from tractor to implement.
 Mark the length to be cut off on the outer
protective tube.
 Remove the outer protective tube and
the inner protective tube.
 Cut off the marked piece of the outer
protective tube.
 Shorten the inner protective tube to the
same length as the outer protective tube.
 Hold the cut-off piece of the outer pro-
tective tube (2) over the outer profile tu-
be (8) and cut the outer profile tube (8)
at a right angle.
